Self Drilling Screw SDS #12 (5.5mm) x 25mm Hex head Mild Steel MS Zinc Plated with Rubber and Metal Washer
Dispatched same day if ordered before 1:00 PM (Excluding Sunday & National holidays), then courier normally takes 2-4 days.
Specifications
| P.Code | Material | W-Width of Head mm |
H-Head Height mm |
L-Length mm |
Thread Diameter mm |
Drill Diameter mm |
Head Drive | Thread Guage No. |
|---|---|---|---|---|---|---|---|---|
| 15398 | Mild Steel MS | 16 | 5 | 25 | 5.5 | 4.2 | HEX8 | #12 |
Direct mount these screw on metal without drilling or tapping, Huge timer saver since these contain a drill point at its tip. We use these in control panel to mount DIN panel for MCBs and PVC wire guide. All you need is a electric screw driver.
Drilling, Tapping, Fastening in single quick operation using electric screw driver on Sheet Metal or PVC Panels,
All three operation in single cycle.
Low profile washer head self-drilling screws are a medium duty metal to metal screw, with a large 'washer' head which has a flat finish on the underside. This makes it ideal to for fixing thin sheet material, as the wafer head provides both excellent clamping and a sleek low profile finish. Washer head screws have an medium duty zinc CR3 plating to provide rust resistance.
- PH2 Philips drive washer head
- 8g x 5/8'' Imperial size
- Zinc CR-3 plated
Features
- Large head Ø for increased clamping.
- Coarse 60 degree self-tapping thread for extreme grip & excellent pull out
- Zinc CR3 plating
- Phillips No2 recess for a positive drive
